The Tplink 300Mbps Wireless N Router TL-WR845N provides speedy and stable Wi-Fi for your network needed devices. Up to 300Mbps wireless speed makes it a practical solution for home network applications like files download, video chat or online streaming.
Three 5dBi high gain antennas perfect for small to medium house, a better coverage lets you never lost connections and enjoy more stable connection.
Delicate Appearance
The new design with elegant texture makes it a stylish addition to the decor of any room in your home.
Guest Network Access
Guest Network function provides secure access for guests to sharing your Wi-Fi network. Easy sharing, no worry about your private network.
Easy Parental Control
Parent Control allow parents or administrators to deploy restricted access for children or staff. With URL blocking, you can easily set up a black or white list to limit the level of web access
Easy Setup and Manage
Set up the Tplink 300Mbps Wireless N Router TL-WR845N in minutes thanks to its intuitive web interface and the powerful Tether app. TP-LINK Tether app provides the easiest way to access and manage your router on your smartphone, allows you to start enjoying your new device faster than ever!
- IP based bandwidth control allows administrators to determine how much bandwidth is allotted to each PC
- Compatible with IPv6 -the more recent Internet Protocol version
- TP-LINK Tether App allows quick installation and easy management using any mobile device
HARDWARE FEATURES FOR TPLINK 300MBPS WIRELESS N ROUTER TL-WR845N
INTERFACE
4 10/100Mbps LAN PORTS
1 10/100Mbps WAN PORT
BUTTON
Reset Button
Wi-Fi/WPS Button
Power On/Off Button
EXTERNAL POWER SUPPLY
9VDC / 0.6A
WIRELESS STANDARDS
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
DIMENSIONS ( W X D X H )
9.1 x 5.7 x 1.4 in.(230 x 144 x 35 mm)
ANTENNA
3*5dBi Fixed Omni Directional Antenna
WIRELESS FEATURES
FREQUENCY
2.4-2.4835GHz
SIGNAL RATE
- 11n: Up to 300Mbps(dynamic)
- 11g: Up to 54Mbps(dynamic)
- 11b: Up to 11Mbps(dynamic)
RECEPTION SENSITIVITY
270M: -70dBm@10% PER
130M: -74dBm@10% PER
108M: -74dBm@10% PER
54M: -77dBm@10% PER
11M: -87dBm@8% PER
6M: -90dBm@10% PER
1M: -98dBm@8% PER
TRANSMIT POWER
CE:
<20dBm
FCC:
<30dBm
WIRELESS FUNCTIONS
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
WIRELESS SECURITY
64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
SOFTWARE FEATURES FOR TPLINK 300MBPS WIRELESS N ROUTER TL-WR845N
QUALITY OF SERVICE
WMM, Bandwidth Control
WAN TYPE
Dynamic IP/Static IP/PPPoE/
PPTP/L2TP/BigPond
MANAGEMENT
Access Control
Local Management
Remote Management
DHCP
Server, Client, DHCP Client List,
Address Reservation
PORT FORWARDING
Virtual Server, Port Triggering, UPnP, DMZ
DYNAMIC DNS
DynDns, Comexe, NO-IP
VPN PASS-THROUGH
PPTP, L2TP, IPSec (ESP Head)
ACCESS CONTROL
Parental Control, Local Management Control, Host List,
Access Schedule, Rule Management
FIREWALL SECURITY
DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
PROTOCOLS
Support IPv4 and IPv6
GUEST NETWORK
2.4GHz Guest Network x1
OTHERS
CERTIFICATION
CE, FCC, RoHS
PACKAGE CONTENTS
Wireless N Rotuer TL-WR845N
Power supply unit
Ethernet Cable
Quick Installation Guide
SYSTEM REQUIREMENTS
Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7,
Windows8/ 8.1/10
MAC® OS, NetWare®, UNIX® or Linux
ENVIRONMENT
- Operating Temperature: 0℃~40℃ (32℉~104℉)
- Storage Temperature: -40℃~70℃ (-40℉~158℉)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
