Professional High-Power 8-Port Unmanaged Switch with 4 PoE+ Ports
Plug and Play, with PoE Transmission for Surveillance up to 250 m
TL-SF1008P
•
66 W PoE Budget*
•
Plug and Play
•
Transmission Distance up to 250 m**
One-Click Priority Mode
•
PoE Auto Recovery
•
Intelligent Power Management
•
Durable Metal Casing
•
Silent Operation
Dedicated 8-Port Switch with 4-Port PoE+ (66 W Budget) for Numerous Applications
Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 66 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.
Network Video Recorder
Computer
Printer
Surveillance
IP Camera
Conference Calls
IP Phone
Wi-Fi Coverage
Access Points
Power over Ethernet
TL-SF1008P
Router
Internet
4 PoE+ Ports
Up to 30 W on Each Port
Total 66 W Power Budget
Plug and Play, No Configuration Required
•
1
Plug In
•
2
Connect Devices
Internet
IP Phone
IP Camera
Access Points
Router
TL-SF1008P
•
3
Enjoy
Dedicated Design for IP Surveillance
—Up to 250 m Transmissions
With extend mode, the PoE transmission distance reaches up to 250 m*—perfect for IP Camera deployment in large areas.
*The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.
Extend Mode Button
TL-SF1008P ( Extend Mode On )
Up to 250 m
Extended is 10 Mbps/port
×4
Up to Four IP Cameras
TL-SF1008P ( Extend Mode Off )
100 m
Default is 100 Mbps/port
×4
Up to Four IP Cameras
Priority Mode Button
Priority Video
Quality Guaranteed
Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.
System Self-Healing
with PoE Auto Recovery
The switch automatically detects and reboots the PD devices, such as cameras and APs, when they fall offline or go unresponsive, guaranteeing the stable operation of PoE-connected devices, without need for manual monitoring and restart.
Priority Mode Button
IP Camera
IP Camera
PoE Auto Recovery
Power overload
66W
Intelligent Power Management
Intelligent power supply
66W
19W
Intelligent Power Management
When total power consumption exceeds 66 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.
High-Quality Metal
27mm
171mm
98mm
Durable Metal Casing
The interior components of TL-SF1008P are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SF1008P delivers switching performance you can depend on.
•
Compact Desktop Design
•
Wall-Mounting
•
Fanless Design
