Features
- TP-LINK AC750 Wireless Dual Band Router (Archer C20) transmits simultaneous 300 Mbps at 2.4 GHz and 433 Mbps at 5 GHz for 733 Mbps total available bandwidth
- Three external antennas provide stable omnidirectional signal and superior wireless coverage
- Supports three modes：Router，Range Extender and Access Point Modes
- IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize HD streaming
- Parental Controls manage when and how connected devices can access the internet
- Guest Network provides separate access for guests while securing the host network
Specification
HARDWARE FEATURES
Interface
4 10/100Mbps LAN ports
1 10/100Mbps WAN port
Buttons:
WPS/Reset Button
Wireless On/Off Switch
Power On/Off Button
Antennas:
2 × 2.4GHz Antennas
1 × 5GHz Antenna
External Power Supply: 12VDC /1A
Dimensions ( W x D x H ): 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm)
Antenna Type: Two dual band fixed antennas
WIRELESS FEATURES
Wireless Standards
IEEE 802.11ac/n/a 5GHz
IEEE 802.11b/g/n 2.4GHz
Frequency: 2.4GHz and 5GHz
Signal Rate:
5GHz: Up to 433Mbps
2.4GHz: Up to 300Mbps
Reception Sensitivity:
5GHz
11a 6Mbps: -91dBm, 11a 54Mbps: -74dBm
11ac HT20: -66dBm, 11ac HT40: -64dBm, 11ac HT80: -61dBm,
11n HT20: -71dBm, 11n HT40: -69dBm
2.4GHz
11g 54M: -76dBm
11n HT20: -74dBm, 11n HT40: -71dBm
Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security: 64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption
Transmission Power:
CE: <20dBm(2.4GHz), <23dBm(5GHz)
SOFTWARE FEATURES
Quality of Service: WMM, Bandwidth Control
Management:
Access Control
Local Management
Remote Management
Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS: DynDns, Comexe, NO-IP
VPN Pass-Through: PPTP, L2TP, IPSec
Access Control:
Parental Control, Local Management
Control, Host List,
Access Schedule, Rule Management
Firewall Security:
DoS, SPI Firewall
IP Address Filtering/MAC Address Filtering/Domain Filtering
IP and MAC Address Binding
Protocols: Supports IPv4 and IPv6
USB Sharing: Support Samba(Storage)/ FTP Server/Media Server/Printer Server
Guest Network:
2.4GHz guest network × 1
5GHz guest network × 1.
