Overview
Features and Design
Operating System
Available with Windows 10 Pro – for a smooth, versatile PC experience.
Intelligent performance
Brainpower that matches yours: The latest Intel® Xeon® processor Scalable Family powers your most demanding applications. Now featuring a new generation of dual-socket architecture with up to 28 cores per processor (or up to 56 cores when built with dual processors) so you can extract maximum performance for your greatest vision. Accelerate every project: Run your software as fast as possible and get real-time results thanks to this memory expandable machine with up to 768GB of 2933 MHz RDIMM memory. And optional Intel® Optane™ DC Persistent Memory offers up to 2TB capacity to support large data sets.
Drown out distraction: Focus on your tasks with the workstation that’s quieter than ever. A new multichannel thermal design delivers advanced cooling and acoustics for enhanced cooling and quiet operation when your system is under heavy workloads.
Groundbreaking innovation
Featuring a FlexBay design, front access, hot-swappable storage and multichannel thermals to keep it cool under pressure, the Precision 7820 Tower grows with your ideas no matter where they take you. Adapts to your innovations: Your Precision 7820 Tower is ready for complex projects, including virtual reality workflows, with the next generation AMD Radeon Pro™ and highest-performing NVIDIA Quadro® graphics. Your workstation supports up to 500W of graphics power and future graphics options up to 600W of graphics power up to 300W per card (single CPU system with 950W PSU).
No project is too big: Up to six 2.5″ or five 3.5″ drives and front access storage including SATA, SAS and PCIe M.2/U.2 NVMe SSD can be configured for up to 68TB total storage and easily swapped. With the hot-swap feature on the M.2 and U.2 PCIe NVMe SSDs, you can remove drives without shutting down the workstation. Enable increased storage performance with the optional U.2 Intel® Optane™ SSD 905P Solid State Drives.
Tuned performance: Free with your Precision workstation, the Dell Precision Optimizer delivers faster application optimization with a single click compared to HP Advisor*. It also automatically tunes your workstation to run popular ISV applications at the fastest speeds possible, has automated system updates and provides analytics to address resource bottlenecks. Premium customized performance: Upgrade to the new Dell Precision Optimizer premium version, the world’s first AI-based performance optimizer software for workstation*. This program learns the behavior of any user-specified applications, identifies optimization opportunities using machine learning and applies performance improvements.
Mission critical reliability
Stay safe, stay secure
Reduce downtime with Dell Reliable Memory Technology (RMT) Pro. Designed to work with ECC memory, RMT protects your machine from potential crashes by mapping out bad memory locations after the system reboots.
Reliably access your data
Improve the availability of your data with hardware and software optional RAID storage options including PCIe NVMe SSDs and optional Smart Card (CAC/PIV) readers that let you determine who can access your system.
Your work can count on it
Precision Workstations are tested to ensure the high-performance applications you rely on every day run smoothly. Dell ISV-certifications cover the most popular independent software applications.
Ports & Slots
- Power button/Power light | 2. Drive activity light | 3. SD card slot | 4. USB 3.1 ports | 5. USB 3.1 Type-C™ port with PowerShare | 6. USB 3.1 Type-C™ port | 7. Headset port | 8. 5.25 inch bay (optional) | 9. Optical drive | 10. Drive access release latch | 11. Drive carriers | 12. Microphone/Line-in port | 13. PS/2 Mouse port | 14. USB 3.1 ports | 15. Discrete graphics card slot (optional) | 16. Padlock ring | 17. Security cable slot | 18. Power cable connector | 19. Line-out port | 20. Serial port | 21. PS/2 Keyboard port | 22. Network port | 23. USB 3.1 port (supports smart Power-On) | 24. Expansion card slots
Dimensions & Weight
- Height: 417.9 mm (16.45″) | 2. Width: 176.5 mm (6.94″) | 3. Depth: 518.3 mm (20.4″) | Starting weight: 15.9kg (32 lb)*
