Highly efficient A3 mono multifunction devices with enhanced security and optimized energy consumption
•
Machine Type
A3 Monochrome Laser Multifunctional
•
Core Functions
Print, Copy, Scan, Send and Optional Fax
•
Processor Speed
1.6GHz Dual Core Processor
•
Control Panel
Standard: 7 inch TFT LCD WVGA Colour Touch panel
•
Memory
Standard: 2.0GB RAM
•
Storage
- Standard: 64GB eMMC
- Optional: 256GB SSD
•
Interface Connection
NETWORK Standard
1000Base-T/100Base-TX/10-Base-T, Wireless LAN (IEEE 802.11 b/g/n), Wi-Fi Direct Connection
OTHERS Standard:
USB 2.0 (Host) x2, USB 2.0 (Device) x1
•
Paper Input (Standard)
Paper Input (Standard)
•
Paper Supply Capacity (A4, 80 gsm)
- Standard: 1,200 sheets
- Maximum: 2,300 sheets (with Cassette Feeding Unit-AW1)
•
Paper Output Capacity (A4, 80 gsm)
- Standard: 250 sheets
- Maximum: 645 sheets (with Inner Finisher-L1 and Copy Tray-T2)
•
Finishing Capabilities
Collate, Group, Offset, Staple, Hole Punch, Eco Staple, Staple On Demand
•
Supported Media Types
Main Body Cassette (Upper/Lower)
Thin, Plain, Recycled, Color, Heavy, Bond, Pre-Punched, Letterhead, PostCardMulti-purpose Tray:
Thin, Plain, Recycled, Color, Heavy, Bond, Pre-Punched, Letterhead, PostCard, Labels, Coated, Tracing
•
Supported Media Sizes
Upper Cassette
- Standard size: A4, A5, A5R, A6R, B5
- Custom Size: 105.0 x 148.0 mm to 297.0 x 215.9 mmLower Cassette:
- Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, COM 10 No. 10*, Monarch*, DL*
Custom Size: 105 x 148 mm to 304.8 x 457.2 mm
*Requires Envelope Attachment A (std)
•
Supported Media Weights
Main Body Cassette (Upper/Lower): 52 to 256 gsmMulti-purpose tray: 52 to 300 gsm
Duplex: 52 to 220 gsm
•
Warm-up Time
4 Seconds or LessFrom Sleep Mode: 10 seconds or less
From Power On: 10 Seconds or Less
•
Dimensions (W x D x H)
565 x 693 x 852 mm
•
Installation Space (W x D)
1,286 x 1,122 mm (with DADF-AZ2 + Inner Finisher tray max extended + Copy Tray-T2 max extended + paper cassette opened）
•
Weight
Approx. 65 kg
