Key Features
- Output power capacity : 1.2kWatts / 2.2kVA
- Output Connections : (6) IEC 320 C19 (Battery Backup)
- Nominal Output Voltage : 230V
- Nominal Input Voltage : 230V
- Input Connections : IEC 60320 C20
- Cord Length : 1.2meters
- Audible alarms – Provides notification of changing utility power and UPS power conditions
- LED Indicators – Provide easy-to-read status of the unit and utility power conditions.
- Battery backup and surge protection – Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.
- Battery and surge protected outlets – Back up and protect your hardware and data during power outages, surges and spikes .
- Sleek design – Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.
- Boost Automatic Voltage Regulation (AVR) – Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
- Cold-start capable – Provides temporary battery power when the utility power is out.
- Transformer-block spaced outlets – Protect equipment with input transformer blocks without blocking access to other receptacles.
- Battery failure notification – Provides early-warning fault analysis on batteries enabling timely preventive maintenance
- Intelligent battery management – Maximizes battery performance, life, and reliability through intelligent, precision charging.
- Advanced Safety Features – Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.
SPECIFICATIONS
UPS topology
Line-Interactive
Output power capacity
2.2 kVA
Output power
1200 W
Waveform
Sine
Input operation voltage (min)
140 V
Input operation voltage (max)
300 V
Input frequency
50/60 Hz
Output frequency
50/60 Hz
Automatic Voltage Regulation (AVR)
Surge energy rating
273 J
Response time
6 ms
Audible alarm(s)
PORTS & INTERFACES
AC outlet types
Type F
Power plug
Type F
BATTERY
Battery recharge time
6 h
Cold start
DESIGN
Product colour
Black
Cable length
1.2 m
LED indicators
Certification
CE, EN/IEC 62040-1, EN/IEC 62040-2
OPERATIONAL CONDITIONS
Operating temperature (T-T)
0 – 40 °C
Storage temperature (T-T)
-15 – 40 °C
Operating relative humidity (H-H)
0 – 95%
Operating altitude
0 – 914.4 m
Non-operating altitude
0 – 914.4 m
WEIGHT & DIMENSIONS
Width
140 mm
Depth
390 mm
Height
190 mm
Weight
12.2 kg
PACKAGING DATA
Cables included
Input power cable
Package width
235 mm
Package depth
495 mm
Package height
297 mm
Package weight
13.2 kg
